Machine and metrology manufacturing services
The Center for Manufacturing Innovation (CMI) is a unique collaboration between Greenville Technical College, Clemson University, manufacturing technology suppliers and local industry. As an Enterprise Campus, the manufacturing capabilities of CMI are available to industry partners, start-up firms and other manufacturers seeking to develop, prototype and manufacture new products. As experts in their fields, the manufacturing and engineering technology faculty and staff of CMI can capably and efficiently support manufacturing firms develop new products.
For industry-client projects, equipment will be operated by Greenville Technical College employees unless the client has been qualified by Greenville Technical College administration to safely operate equipment at CMI.
For rates and availability, contact:
Mary Hendrix, Office Manager
GTC Center for Manufacturing Innovation
(864) 236-6723
Mary.Hendrix@gvltec.edu
HAAS UMC 750 5-AXIS MACHINING CENTER
Manufacture precision-machined metal components with complex geometries requiring full 5-axis machining capability. The Haas UMC 750 offers a large work volume, with a 500 mm integrated 2-axis trunnion rotary table, 40 taper, 30 hp vector drive. Achieve precise tolerances with Renishaw probing and ballbar calibration.
Key Specifications:
Work Volume: 762 mm × 508 mm × 508 mm
8100 RPM Inline Direct-Drive 40-Taper Spindle Dynamic Work Offsets & High Speed Machining Capable 40+1 Side-Mount Tool Changer
Wireless Intuitive Probing System
Through-Spindle Coolant System
MITUTOYO CRYSTA APEX 9106 COORDINATE MEASURING MACHINE
Precisely and accurately measure critical features with the Mitutoyo Crysta Apex 9106 CMM. This CMM offers a wide measurement range and unmatched accuracy among CMMs of the 1.7µm class. Capabilities are extended with additional Renishaw probing, Mitutoyo SurfaceMeasure non-contact laser probe and Surftest surface roughness measuring probe. The CMI CMM is in a temperature controlled and vibration-isolated environment.
Key Specifications:
Measurement Volume: 900 mm × 1000 mm × 600 mm
Resolution: 0.0001mm
Maximum Measurement Error: 1.7+4(L/1000mm) µm [L = measuring length]
HAAS ST20-Y CNC LATHE
The Haas ST20-Y is capable of turning complex components, accurately and efficiently. Complete with live tooling, a 305 mm maximum cutting diameter, and 533 mm maximum cutting length, the ST20-Y offers a 806 mm swing.
Key Specifications:
Chuck Size: 210 mm
Max Rating: 14.9 kW
Max Speed: 4000 RPM
12 Station Tool Holder
6000 RPM Live Tooling Max Speed
CNC MACHINE SHOP
In addition to 5-axis CNC machines and CNC lathes, the CMI machine shop is completely outfitted with manual mills, lathes, automatic grinders, wire EDM, and vertical and horizontal band saws to tackle any metalworking application. The talented faculty, students and staff of CMI are eager to engage in prototyping or process improvement projects to assist businesses grow and innovate.
